9 Trip Length Distribution

9.1 Purpose

This job can create trip length distribution for a normal matrix or for a select link matrix or any matrix. One of these matrices is then combined with a skim matrix of choice.

9.2 Inputs

This job can be run in two ways.The first method uses regular ranges for the x-axis and the second method uses irregular ranges.The regular ranges are specified using a min, max and interval. The irregular ranges are specified using an array of lower limits and an array of upper limits.

9.2.1 Method 1 - Regular Ranges

Following are the inputs to this job. You will also need a encrypted file tld.rc in your job folder.

The following parameters are used to select the matrices and create a table.

The parameter mode_matrix_number: is the matrix number of the trip matrix.
The parameter skim_matrix_number: is the matrix number of the skim matrix.
The parameters used for the chart are also used for the table.

The following parameters are used for plotting a chart. These 3 values will come based on the skim matrix.

The parameter x_axis_max: is the maximum distance you want to show on the x-axis.
The parameter x_axis_min: is the minimum distance you want to show on the x-axis.
The parameter x_axis_interval: is the interval on the x-axis.

Important

To specify the x-axis min max, open your skim matrix in Omnitrans and check the min max values. Be sure to check that the Total trips in the matrix is same as Total trips in the frequency table. Both these values are shown in the output of this job. If they are not the same, your classes in the frequency table do not cover the entire range of distances in the skim matrix.

$mode_matrix_number = [1,11,10,1] # trip matrix
$skim_matrix_number = [1,11,10,1,13,1]  # skim matrix

$x_axis_max = 11 # max value on x-axis
$x_axis_min = 0 # min value on x-axis
$x_axis_interval =  1 # interval on x-axis

9.2.2 Method 2 - Irregular Ranges

Following are the inputs to this job. You will also need a encrypted file tld.rc in your job folder.

The following parameters are used to select the matrices and create a table.

The parameter mode_matrix_number: is the matrix number of the trip matrix.
The parameter skim_matrix_number: is the matrix number of the skim matrix.
~~The parameters used for the chart are also used for the table.~~

The following parameters are used for a generating a frequency table. These 2 values will come based on the skim matrix.

The parameter x_axis_min: is an array of lower limits of the class on x-axis.
The parameter x_axis_max: is an array of upper limits of the class on x-axis.
The parameter x_axis_interval: is always set to zero.

Important

$mode_matrix_number = [1,11,10,1] # trip matrix
$skim_matrix_number = [1,11,10,1,13,1]  # skim matrix

$x_axis_min = [0,10,20,40] # lower limits
$x_axis_max = [10,20,40,100] # upper limits
$x_axis_interval =  0 # interval on x-axis

9.3 Outputs

Following are the outputs to this job:

A tabular format that you can copy paste into excel.
A chart that you can save as an image
No chart is created for irregular ranges (Method 2).

9.4 Code

Download the encrypted file tld.rc

# OmniTRANS Job for 'Delft Tutorial Static'
# Created 2-9-2025 13:17:16
# Author 'Srirama'

=begin
This script creates a trip length distribution chart
based on trip and distance matrices. It uses the OtChart library
to visualize the distribution of trips by distance.
=end

require "OtChart"



# INPUTS

$mode_matrix_number = [1,11,10,1] # trip matrix
$skim_matrix_number = [1,11,10,1,13,1]  # skim matrix

$x_axis_min = 0
$x_axis_max = 11
$x_axis_interval =  1

# Uncomment the following lines for irregular ranges
# $x_axis_min = [0,10,20,40] # lower limits
# $x_axis_max = [10,20,40,100] # upper limits
# $x_axis_interval =  0 # interval on x-axis


requireCrypted($Ot.dirJob+"tld.rc")
